B1714 BMW Fault Code

Description:

Variable Cam Timing Over-advanced (Bank 1) The comprehensive component monitor (CCM) monitors the VCT position for an over-advanced camshaft timing.
The test fails when the camshaft timing exceeds a maximum calibrated value or remains in an advanced position.

BMW cam timing improperly set No oil flow to the VCT piston chamber Low oil pressure VCT solenoid valve stuck closed Camshaft advance mechanism binding (VCT unit) B1714 DTC is a check of the VCT unit.

B1714 Code Symptoms :

The B1714 Check Engine lamp is perhaps the most troubling of lights because it could mean so many different things, from you didn't screw the gas cap on tightly enough to look out for pistons flying through the hood and into the stratosphere. The easiest way to find out what this light is telling you is to hook your vehicle up to a scan tool. B1714 diagnostic tool looks a little like an oversized calculator and plugs into a communication port inside the car. After you instruct it to perform the scan, it speaks with your car's computers to find out exactly what's prompting the light to turn on.

Diagnosis And Repairing B1714

B1714 the main thing to check is to verify the operation of the VCT solenoid. You're looking for a sticking or stuck VCt solenoid valve caused by contamination. Refer to vehicle specific repair manual to perform component tests for the VCT unit.

How to fix B1714 code ?

• Erratic camshaft position due to low oil pressure
• Faulty Air fuel ratio (A/F) Sensor 1 Bank 1
• Intake Valve Timing Control Solenoid Valve harness is open or shorted
• Damaged ECM

Circuit High Input codes like B1714 are mostly caused by defective alternators that develop excessive voltages, although there may be other causes as well, such as short circuits that 'leak' current into a particular system from other, unrelated systems that work on higher voltages. Note that in the case of short circuits that leak power into a control circuit, there is likely to be other, seemingly unrelated trouble codes present along with the code(s) being investigated. Diagnosing a 'high input' code will always involve a thorough testing of the charging system as a first step, followed by measures to isolate the system from all other possible sources of power during resistance, continuity, and reference voltage tests.
